Protective box for box and winch

Protect your winches and boxes without disassembly

This red metal protective enclosure is designed to protect mechanical winches and CO₂ boxes. It can be installed without dismantling on existing equipment, making it easier to protect existing installations .

Access and secure closure

Opening is via a triangle key lock (6.5 mm high triangle). An 8 mm key is supplied with the box for access and maintenance.

Cable passages and equipment compatibility

The box has outlets for electrical cables, copper tubes and the winch cable at the top and bottom. It can contain equipment with maximum dimensions of H200 × W120 × D110 mm.

Installation and fixing points

The enclosure can be fixed without removing the equipment already in place. The fixing center distances indicated are H202 × L150 and the dimension of the opening at the rear of the enclosure is H206 × L130, useful information for installation.

Practical use

Designed to protect winches and CO₂ boxes during installation, it makes interventions easier thanks to its supplied key and its organized cable passages.

Features of the Protective Case for Box and Winch:

- Material: Metal
- Height: 250 mm
- Width: 190 mm
- Depth: 125 mm
- Weight: 2.76 kg
- Closure: standard firefighter lock
- Key: 8 mm triangle provided
- Maximum interior capacity: H200 × W120 × D110 mm
