Electromagnetic module for pneumatic box
In stock
9655
24 VDC electromagnetic break module designed to trigger a pneumatic system when there is a voltage failure . It is installed near the opening lever and can operate up to two levers via its T-arm.
Log in to know your accessibility to the product and its price
Technical guides
These products may also interest you
| Product | Reference | Landmark | Designation | Price | Availability | Quantity |
|---|---|---|---|---|---|---|
|
9604
|
- |
Price
€81.60
HT
|
In stock
|
|
|
|
9605
|
- |
Price
€100.20
HT
|
In stock
|
|
|
|
9651
|
- |
Price
€173.55
HT
|
In stock
|
|
|
|
9652
|
- |
Price
€180.05
HT
|
1 to 3 weeks
|
|
|
|
9653
|
- |
In stock
|
|||
|
9656
|
- |
In stock
|
Description
Trigger your pneumatic boxes in the event of a power outage
This 24 Vdc electromagnetic module operates in power failure mode: when a power outage occurs, it mechanically releases its T-shaped arm, driving the lever(s) of the CO₂ box and causing the cartridges to strike to start the pneumatic system.
Compatible with CO₂ boxes ref. 9651, 9652 and 9653.
Installation and fixing
The module is installed near the cabinet opening lever. It comes with an M5 screw and a D5 washer for attaching it to the cabinet. The T-arm allows two levers (left and right) to be operated simultaneously if necessary.
Features of the electromagnetic module for CO₂ box:
- Material: Metal
- Height: 154 mm
- Width: 61.8 mm
- Depth: 65.2 mm
- Power supply: 24 Vdc
- Power: 1.6 W
- Weight: 0.54 kg
- Compatibility: CO2 box (Ref. 9651, 9652, 9653)
