Flow meter for DN65 column
In progress of replenishment
(1 to 2 weeks)
0185
Control of flow and pressure loss of fire columns
To connect at the bottom of the column
Log in to know your accessibility to the product and its price
Technical guides
These products may also interest you
| Product | Reference | Landmark | Designation | Price | Availability | Quantity |
|---|---|---|---|---|---|---|
|
0188B
|
- |
Price
€91.40
HT
|
In stock
|
|
Description
Equipped with a Woltmann turbine, this flow meter allows you to control the flow rate and pressure loss of the fire columns using a pressure gauge and an analog screen.
The display can be submerged because it is IP68 waterproof and indicates at each check the elapsed volume of the test as well as the cumulative.
The foam handle of the DB100C-M combined with its compact size provides excellent grip without any fatigue.
Features :
- Automatic start and stop
- Battery life: 10 years (no risk of the battery stopping in the field)
- Flow rate: 85 m3/h (the Woltmann turbine allows the flow meter to display volume and flow with an accuracy of 0.1 m3 (99%))
- Pressure: 25 bars (the color pressure gauge offers a very precise static and dynamic pressure reading from 0.1 to 25 bars)
- Weight: 4.9 kg
- Diameter: DN65
To connect at the bottom of the column
